Pixel 17um Human Online IR Human Temperature Checking Device

Name: Pixel 17um Human Online IR Human Temperature Checking Device
Brand: JOHO
Price: 1 USD

Quality Pixel 17um Human Online IR Human Temperature Checking Device wholesale

Brand Name : JOHO

Model Number : JH-2005B

MOQ : 1

Payment Terms : T/T

Certification : ISO9001

Place of Origin : China

Delivery Time : 5000PCS/Year

Detector : Uncooled Vox FPA

Pixel : 384×288

Pixel size : 17um

Spectral band : 8~14um

Bad pixel : <0.05%

FOV : 24°×19°

Resolution : 1920(H)×1080(V)

Focal length : 4.7mm-94mm continuous zoom

Size : progressive scanning 1/2.8"CMOS

Displayed temperature range : (30~50.0)ºC

Contact Now

JH-2005B Online IR Human Temperature Checking System

Function

Warning value correction function: it has modifiable indication value correction function
It has built-in and external black body automatic correction function.
Image output:Video and images can be sent to the remote control room.

Feature

Climatic and environmental adaptability warning temperature measurement error complies with the climatic and environmental requirement in 4.3.3 of GB/T 19870-2005.It requires working temperature within(10~40)ºC, storage and transportation within(-20~60)ºC ,RH(5~95)% (at 30ºC), storage and transportation ≤90 % (at 40ºC)
Approval certificate issued by the national quality inspection department shall be provided.
The manufacturer promises to upgrade or upgrade the Camera System for free
Installation standard: complete wiring on user requirements; install the host of the infrared camera in the position specified by the user, complete hanging installation to work normally and measure temperature.

Technical Specification

IR detector	Uncooled Vox FPA
Pixel	384×288
Pixel size	17um
Spectral band	8~14um
Bad pixel	<0.05%
FOV	24°×19°
Day light camera
Resolution	1920(H)×1080(V)
Focal length	4.7mm-94mm continuous zoom
Size	progressive scanning 1/2.8"CMOS
Displayed temperature range	(30~50.0)ºC
Temperature resolution	≤0.1ºC
Alarming temperature measurement error	±0.3ºC(Under the specified measuring distance and application environment, when measuring the black body radiation source with diameter of 60mm )
Response time	≤1sec
Calibration mode	a mode for measuring and displaying the temperature of a blackbody source (obtained by conversion)
Working temperature	(10~40)ºC ,humidity:(5~95)%RH

Company Profile
Wuhan JOHO Technology Co., Ltd founded in 2009, is a high-technology company based on infrared thermal imaging technology. Joho has built a complete infrared industrial chain from the bottom up: from core component to comprehensive electro optical infrared surveillance and tracking system.We have two R & D base in Hubei Zhongxiang and Wuhan City, well-known institutions of higher learning and research institutions at home and abroad.
